Accurate P320 SIEMENS Pressure Transmitter 0-16bar 7MF0300-1QD01-5AF1-Z

7MF0300-1QD01-5AF1-Z Siemens P320 Pressure Transmitter 0-16bar

Technical Parameters:

Applications:

SITRANS P320 Pressure transmitter Gauge pressure HART (4...20 mA) Measuring cell filling: Silicone oil Maximum measuring span: 63 bar (914 psi) Male thread G1/2 (DIN EN 837-1) Process connection: Stainless steel 316L/1.4404, Seal diaphragms: Stainless steel 316L/1.4404, Sensor differential pressure: Process flange: Stainless steel 316/1.4408 Die-cast aluminum housing Dual chamber device no Ex 2 x M20 x 1.5 With display (lid with glass window) Cable gland and sealing plug attached, plastic Labeling type plate German - bar Quality inspection certificate - 5 point factory calibration (IEC 60770-2) General approval without Ex approval: World (CE, UKCA, RCM) except: CSA, EAC, FM, KC Measuring range setting: Lower range value (max. 5 characters), Upper range value (max. 5 characters), Unit (mbar, bar, kPa, MPa, psi, ...) Example: -0.5 ... 10.5 psi (stainless steel plate)

Packing and Shipping:

Product Packaging:

• The SIEMENS Pressure Transmitter will be securely packaged in a corrugated cardboard box.
• The box will be sealed with tamper-evident tape to ensure the safety and integrity of the product during shipping.
• Inside the box, the product will be cushioned with foam inserts to prevent any damage during transit.
• The product will also come with a user manual and any necessary installation hardware.

Shipping:

• The SIEMENS Pressure Transmitter will be shipped via a reputable carrier such as UPS or FedEx.
• Customers can choose from various shipping options, including standard, expedited, and overnight delivery.
• Shipping costs will be calculated based on the customer's location and desired shipping method.
• Once the product is shipped, customers will receive a tracking number to monitor the delivery status of their package.
